FUSHENG AIR COMPRESSOR
- SA+SERIES
- 兩段螺旋式空壓機
Two-Stage
125HP – 330HP
Screw Air Compressor
90kW – 250kW
- Low pressure difference
- Low heat-load
- Easy maintenance
- Reduce energy loss
- Computerized self-diagnosis
- Safety protection
Reduce energy loss
- 15% less energy loss comparing to single-stage air compressors
Low pressure difference
- Air-let valve with precise pressure control for high efficiency and energy-saving
e-COOL™ Technology
- Independent cooling airflow
- Lower internal temperature
FUSHENG SA+ Series 2-Stage Screw Air Compressor
SA+ Series 2-Stage Air-cooled
|
Model |
Working pressure |
Delivery | Main motor power |
Length | Width | Height | Weight | |
| barG | m3/min | kW | HP | mm | mm | mm | kg | |
| 50 Hz | ||||||||
| SA90A-7T | 7 | 19.5 |
90 |
125 |
2900 |
1860 |
1945 |
4000 |
| SA90A-8T | 8 | 18.2 | ||||||
| SA90A-10T | 10 | 16.3 | ||||||
| SA90A-12T | 12 | 14.6 | ||||||
| SA110A-7T | 7 | 23.5 |
110 |
150 |
2900 |
1860 |
1945 |
4350 |
| SA110A-8T | 8 | 22 | ||||||
| SA110A-10T | 10 | 19.2 | ||||||
| SA110A-12T | 12 | 17.8 | ||||||
| SA132A-7T | 7 | 27.6 |
132 |
175 |
2900 |
1860 |
1945 |
4200 |
| SA132A-8T | 8 | 26.1 | ||||||
| SA132A-10T | 10 | 23.2 | ||||||
| SA132A-12T | 12 | 21.5 | ||||||
| SA160A-7T | 7 | 34 |
160 |
215 |
3520 |
2290 |
2030 |
4480 |
| SA160A-8T | 8 | 32.3 | ||||||
| SA160A-10T | 10 | 28.6 | ||||||
| SA160A-12T | 12 | 26.5 | ||||||
| SA200A-7T | 7 | 43.1 |
200 |
270 |
4200 |
2300 |
2300 |
7000 |
| SA200A-8T | 8 | 40.5 | ||||||
| SA200A-10T | 10 | 35 | ||||||
| SA200A-12T | 12 | 31 | ||||||
| SA220A-7T | 7 | 47.5 |
220 |
300 |
4200 |
2300 |
2300 |
7000 |
| SA220A-8T | 8 | 44.5 | ||||||
| SA220A-10T | 10 | 38.7 | ||||||
| SA220A-12T | 12 | 34.2 | ||||||
| SA250A-7T | 7 | 54.3 |
250 |
335 |
4200 |
2300 |
2300 |
7000 |
| SA250A-8T | 8 | 51.5 | ||||||
| SA250A-10T | 10 | 45.3 | ||||||
| SA250A-12T | 12 | 40 | ||||||
SA+ Series 2-Stage Water-cooled
|
Model |
Working pressure |
Delivery | Main motor power |
Length | Width | Height | Weight | |
| barG | m3/min | kW | HP | mm | mm | mm | kg | |
| 50 Hz | ||||||||
| SA90W-7T | 7 | 19.5 |
90 |
125 |
2900 |
1860 |
1945 |
4000 |
| SA90W-8T | 8 | 18.2 | ||||||
| SA90W-10T | 10 | 16.3 | ||||||
| SA90W-12T | 12 | 14.6 | ||||||
| SA110W-7T | 7 | 23.5 |
110 |
150 |
2900 |
1860 |
1945 |
4250 |
| SA110W-8T | 8 | 22 | ||||||
| SA110W-10T | 10 | 19.2 | ||||||
| SA110W-12T | 12 | 17.8 | ||||||
| SA132W-7T | 7 | 27.6 |
132 |
175 |
2900 |
1860 |
1945 |
4200 |
| SA132W-8T | 8 | 26.1 | ||||||
| SA132W-10T | 10 | 23.2 | ||||||
| SA132W-12T | 12 | 21.5 | ||||||
| SA160W-7T | 7 | 34 |
160 |
215 |
3520 |
2290 |
2030 |
4380 |
| SA160W-8T | 8 | 32.3 | ||||||
| SA160W-10T | 10 | 28.6 | ||||||
| SA160W-12T | 12 | 26.5 | ||||||
| SA200W-7T | 7 | 43.1 |
200 |
270 |
4200 |
2300 |
2300 |
6500 |
| SA200W-8T | 8 | 40.5 | ||||||
| SA200W-10T | 10 | 35 | ||||||
| SA200W-12T | 12 | 31 | ||||||
| SA220W-7T | 7 | 47.5 |
220 |
300 |
4200 |
2300 |
2300 |
6500 |
| SA220W-8T | 8 | 44.5 | ||||||
| SA220W-10T | 10 | 38.7 | ||||||
| SA220W-12T | 12 | 34.2 | ||||||
| SA250W-7T | 7 | 54.3 |
250 |
335 |
4200 |
2300 |
2300 |
6500 |
| SA250W-8T | 8 | 51.5 | ||||||
| SA250W-10T | 10 | 45.3 | ||||||
| SA250W-12T | 12 | 40 | ||||||
